Antec HCG1000 Extreme 80 Plus Gold Series 1000 Watt Full Modular Power Supply

HCG 1000 EXTREME


High Current Gamer Extreme Series 1000W


  • Guaranteed 1000W of Continuous Power from Antec
  • 100% ModularImproves airflow and reduces clutter
  • 80 PLUS® GOLD certifiedUp to 92% efficient, to reduce your electricity bill
  • PhaseWave™ DesignA server-class full-bridge LLC design with a synchronous rectification based on a DC-DC topology
  • 16 pin SocketIndustry-leading 16-pin sockets double the modular connectivity by supporting 2 different 8-pin cables per socket and allow for future connector changes
  • Antec Quality 10-year warranty and lifetime global 24/7 support
  • 135mm FDB SilenceWhisper-quiet high-quality fluid-dynamic bearing fan with long lifetime
  • Zero RPM ManagerAn advanced low voltage fan control with fan-off mode at low loads for absolute silence
  • 99%+12V - Output for maximum CPU & GPU support
  • CircuitShield™Full suite of industrial grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
  • 100% Japanese capacitors achieve unprecedented tight voltage regulation & low ripple & noise to maximize your system’s performance
  • 28(18+10) pin MBU socket - For possible future MBU connectors
  • ATX12V 2.4Engineered according to the newest PSU guideline and compatible with the latest CPU generation
  • HCG Extreme delivers non-stop industrial class performance for high-end computer systems at up to 50°C ambient.


Specification

Dimension (W x L x H)

160(L) x 150(W) x 86(H)

Input Voltage

100-240 VAC ±10%

Type

ATX 12V 2.4

Input Frequency Range

50Hz-60Hz

PFC

Active PFC (>0.9 typical)

Fan

135mm FDB Fan

Power Good Signal

100-500ms

Efficiency

92% Typically

Modular

Fully Modular

Protection

OCP/OVP/UVP/SCP/OPP/OTP/SIP/NLO

Output Capacity

1000W

Operation Temperature

0~50°C

Regulatory

cTUVus/TUV/CB/RCM/CE/EAC/CCC/BSMI/FCC/KR

Certifications

80 Plus Gold

Connector

1 x MB 24(20+4) Pin 2 x 8(4+4) Pin EPS 12V 8 x 8(6+2) Pin PCI-E 12 x SATA 6 x Molex 1 x FDD

Model

HCG1000 Extreme

Warranty

10 years

Note*

Price, feature and specifications are subject to change without notice
