- Model: NE550M V2 GB
NeoECOMODULAR 550 v2 High-Efficiency Power Supply
NE550M V2 GB
Get economical power today with the NeoECO Modular, Antec's high-efficiency power supply solution. Featuring 80 PLUS® BRONZE certification, a quiet 120 mm fan, Japanese capacitors and Universal Input with Active Power Factor Correction, NeoECO Modular gives you a cooler, quieter system, all powered by Continuous Power.
80 PLUS Bronze Certified
Up to 88% efficient,to reduce your electricity bill.
Japanese Heavy-duty Caps
Japanese High-performance capacitors ensure tightest DC stability and regulation.
120mm silent Fan
Whisper-quiet high-quality silent fan with long lifetime.
|
Specification |
|
|
Model |
NE550M V2 |
|
Type |
ATX 12V 2.4 |
|
Modular |
Semi-Modular |
|
Dimension |
140(L) x 150(W) x 86(H) |
|
Input Voltage |
100-240 VAC |
|
Input Current |
8A-4A |
|
Input Frequency Range |
47Hz-63Hz |
|
PFC |
Active PFC |
|
Power Good Signal |
100-500ms |
|
Efficiency |
Up to 88% |
|
Protection |
OCP / OVP / UVP / SCP / OPP / NLO |
|
Output Capacity |
550W |
|
Operation Temperature |
0~40°C |
|
Regulatory |
cTUVus / TUV / CB[IEC62368 Compliant] / RCM / |
|
Fan |
120 mm Silence Fan |
|
Certifications |
80 Plus Bronze |
|
Connector |
1 x MB 24(20+4) Pin 1 x 8(4+4) Pin EPS 12V 2 x 8(6+2) Pin PCI-E 5 x SATA 3 x Molex |
|
Net Weight |
2.20 Kgs |
|
Gross Weight |
2.33 Kgs |
|
Warranty |
5 years |
|
Note* |
Price, feature and specifications
are subject to change without notice |
