Model

ACFRE00144A

Compatibility

Intel:1700

AMD:AM5, AM4

PI | NNPI:338 | 309

TIM:MX-6 (0.8 g)

Operating Ambient Temperature:0—40 °C

Weight: 1870 g

LED Connector:3-Pin A-RGB Connector

All-In-One Connector:4-Pin PWM Connector

Splitt Connector:3x 4-Pin PWM Connector

Pump

Pump:800—2800 rpm (PWM controlled)

Current | Voltage:0.35 A | 12 V DC

Cold Plate:Copper, Micro Skived Fins

Tube Length:450 mm

Tube Diameter:Outer: 12.4 mm

Inner:6.0 mm

Radiator

Material:Aluminium

Dimensions: 398 (L) x 120 (W) x 38 (H) mm

VRM Module

VRM Fan:400—2500 rpm (PWM controlled)

Current | Voltage:0.05 A | 12 V DC

LEDs:12x A-RGB LEDs

Current | Voltage:0.40 A | 5 V DC

Fan

Fan:3x P12 PWM PST A-RGB

Speed:200—2000 rpm

Air Flow:48.82 cfm | 82.91 m3/h

Static Pressure:1.85 mmH2O

Bearing:Fluid Dynamic Bearing

Current | Voltage:0.11 A | 12 V DC

Cable Lenght:40 mm

Connector:4-Pin PWM Connector

RGB

LEDs:12x A-RGB LEDs

Current | Voltage:0.40 V | 5 V DC

Cable Lenght:40 mm + 80 mm Splitter Cable

Connector:3-Pin A-RGB Connector + 3-Pin Plug

Packaging

Width: 167 mm

Height: 142 mm

Length: 414 mm

Weight: 2.43 kg

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
