Fan Specs

Fan Speed: 400–2500 rpm, PWM controlled 0 rpm below 5 % PWM

Airflow: 110 cfm | 186 m³/h

Static Pressure: 5.2 mmH2O

Fan Bearing: Fluid Dynamic Bearing

Typical Voltage: 12 V DC

Start Up Voltage: 5 V DC

Current: 0.35 A

Cable Length: 400 mm + 80 mm Daisy-Chain Cable

Connector: 4-Pin Fan Plug + 4-Pin Socket

Operating Ambient Temperature

0–40 °C

Dimensions

140 (L) x 140 (W) 27 (H) mm

Net Weight

242

Packaging

Width: 145 mm

Height: 32 mm

Length: 145 mm

Weight: 0.294 kg

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
