- Model: RX5600XT-CLD-6GO
AMD Radeon RX 5600 XT Challenger D 6G OC
RX5600XT CLD 6GO
Clock: GPU / Memory
- Boost Clock: Up to
1620* MHz / 14 Gbps**
- Game Clock: Up to
1460* MHz / 14 Gbps**
- Base Clock: 1235*
MHz / 14 Gbps**
Key Specifications:
- Radeon RX 5600 XT
Graphics
- 2nd Gen 7nm GPU
- 6GB 192-bit GDDR6
- 1 x 8-pin Power
Connector
- 3 x DisplayPort / 1
x HDMI
Key Features:
- Dual Fan Design
- Metal Backplate
- AMD Eyefinity
Technology
- Radeon FreeSync™ 2
HDR
*Need to update L07
version VBIOS or later
**Need to update
L08 version VBIOS or later
Specification | |
Graphics Engine | AMD Radeon RX 5600 XT |
Bus Standard | PCI® Express x16 Gen4 |
DirectX | 12 |
OpenGL | 4.6 |
Memory | GDDR6 6GB |
Engine Clock | Boost Clock: Up to 1620 MHz Game Clock: Up to 1460 MHz Base Clock: 1235 MHz *Need to update L07 version VBIOS or later |
Stream Processors | 2304 |
Memory Clock | 14 Gbps *Need to update L08 version VBIOS or later |
Memory Interface | 192-bit |
Resolution | Digital Max Resolution: 8K HDR 60Hz |
Interface | 1 x HDMI 2.0b 3 x DisplayPort 1.4 with DSC 1.2a |
HDCP | Yes |
Multi-view | 4 |
Recommended PSU | 550W |
Power Connector | 1 x 8-Pin |
Accessories | 1 x Quick Installation Guide |
Dimensions | 240.5 x 126.5 x 53 mm |
Warranty | 3 years |
Note* | Price,
feature and specifications are subject to change without notice |
