- Model: ROG-STRIX-RTX3080TI-O12G-GAMING
ROG-STRIX-RTX3080TI-O12G-GAMING
ROG Strix GeForce RTX™ 3080 Ti OC Edition 12GB GDDR6X buffed-up design with chart-topping thermal performance.
- NVIDIA Ampere Streaming Multiprocessors: The building blocks for the world’s fastest, most efficient GPUs, the all-new Ampere SM brings 2X the FP32 throughput and improved power efficiency.
- 2nd Generation RT Cores: Experience 2X the throughput of 1st gen RT Cores, plus concurrent RT and shading for a whole new level of ray tracing performance.
- 3rd Generation Tensor Cores: Get up to 2X the throughput with structural sparsity and advanced AI algorithms such as DLSS. These cores deliver a massive boost in game performance and all-new AI capabilities.
- OC edition: Boost clock 1845 MHz (OC mode)/ 1815 MHz (Gaming mode)
- Axial-tech Fan Design has been tuned up with more fan blades and a reversed rotational direction for the center fan.
- 2.9-slot design expands cooling surface area compared to last gen for more thermal headroom than ever before.
- Super Alloy Power II includes premium alloy chokes, solid polymer capacitors, and an array of high-current power stages.
- GPU Tweak II provides intuitive performance tweaking, thermal controls, and system monitoring.
|
Specification |
|
|
Graphic Engine |
NVIDIA® GeForce RTX™ 3080 Ti |
|
Bus Standard |
PCI Express 4.0 |
|
OpenGL |
OpenGL®4.6 |
|
Video Memory |
12GB GDDR6X |
|
Engine Clock |
OC mode : 1845 MHz (Boost Clock) |
|
CUDA Core |
10240 |
|
Memory Speed |
19 Gbps |
|
Memory Interface |
384-bit |
|
Resolution |
Digital Max Resolution 7680 x 4320 |
|
Interface |
Yes x 2 (Native HDMI 2.1) Yes x 3 (Native DisplayPort 1.4a) HDCP Support Yes (2.3) |
|
Maximum Display Support |
4 |
|
NVlink/ Crossfire Support |
No |
|
Accessories
|
1 x ROG Velcro Hook & Loop |
|
Software |
ASUS GPU Tweak II & GeForce Game Ready Driver & Studio Driver: please download all software from the support site. |
|
Dimensions
|
318.5 x 140.1 x 57.78 mm |
|
Recommended PSU |
850W |
|
Power Connectors |
3 x 8-pin |
|
Slot |
2.9 Slot |
|
Warranty |
3 Years |
|
Note* |
*Our wattage recommendation is based on a fully
overclocked GPU and CPU system configuration. For a more tailored suggestion,
please use the “Choose By Wattage” feature on our PSU product page:
https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html Price, feature and specifications
are subject to change without notice |
