Chipset

Intel B360

CPU Support

Socket 1151 for 9th & 8th Intel Core i7 / i5 / i3 / Pentium / Celeron processor
* 8th Generation Intel Core™ Processor Family only support 300-Series.
* Please refer to www.biostar.com.tw for CPU support list.

Memory

Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666
2 x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.

Integrated Video

By CPU model
Supports DX12
Supports HDCP

Storage

4 x SATA III Connectors (6Gb/s)
1 x M.2 (M Key) Socket:
Supports M.2 Type 2242/ 2260/ 2280 SSD module
Supports SATA III (6Gb/s) SSD

LAN

Realtek RTL8111E/ RTL8111F/ RTL8111NH (Optional)
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
* The motherboard network chip depends on the motherboard purchased by the user.

Audio Codec

ALC887
7.1 Channels, High Definition Audio

USB

6 x USB 3.1(Gen1) ports (4 on rear I/Os and 2 via internal header)
6 x USB 2.0 ports (2 on rear I/Os and 4 via internal header)

Expansion Slot

11 x PCIe 3.0 x1 Slot
1 x PCIe 3.0 x16 Slot
* Maximum VGA cards mining support are depending on VGA Driver or mining software.

Rear I/O

1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x VGA Port
1 x HDMI Port
1 x LAN port
2 x USB 2.0 Ports
4 x USB 3.1(Gen1) Ports
3 x Audio Jack

Internal I/O

4 x SATA III Connectors (6Gb/s)
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.1(Gen1) Header (each header supports 2 USB 3.1(Gen1) ports)
1 x 8-Pin Power Connector
2 x 24-Pin Power Connectors
2 x 6-Pin PCIe Power Connectors
1 x CPU Fan Connector
2 x System Fan Connectors
1 x Front Panel Header
1 x Front Audio Header
1 x COM Serial Header
1 x Clear CMOS Header

H/W Monitoring

CPU / System Temperature Monitoring
CPU / System Fan Monitoring
System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring

Dimension

ATX Form Factor Dimension: 29.5cm x 21.0cm ( W x L )

OS Support

Supports Windows 10(64bit) / 11(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice.

Bundle Software

BullGuard

Accessories

2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual

Features

PCI-E Slot Detection BIOS Boot Screen

Warranty

1 Year

Note*

Price, feature and specifications are subject to change without notice.
