MODEL

MPE-C501-AFCAG-3EIN

ATX VERSION

ATX Rev 3.1

PFC

Active PFC

INPUT VOLTAGE

100-240V

INPUT CURRENT

15-7A

INPUT FREQUENCY

50-60Hz

DIMENSIONS (L X W X H)

180 x 150 x 86 mm

FAN SIZE

140mm

FAN BEARING

Two Ball Bearing

EFFICIENCY

>90% @ Typical Load

80 PLUS RATING

80 PLUS Gold

ErP 2014 Lot 3

Yes

OPERATING TEMPERATURE

0-50°C

POWER GOOD SIGNAL

100 - 150 ms

HOLD UP TIME

>16ms at 100% Load

MTBF

>100,000 Hours

PROTECTIONS

OVP/ OPP/ SCP/ OCP/ UVP/ OTP/ Inrush Protection

REGULATORY

TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS

ATX 24-PIN

x1 = 1x (650mm)

EPS 4+4 PIN

x1 = 1x (650mm)

EPS 8 PIN

x1 = 1x (650mm)

SATA

x12 = 3x (500+120+120+120mm)

PERIPHERAL 4-PIN

x4 = 1x (500+120+120+120mm)

PCI-E 6+2 PIN

x3 = 3x (550mm)

12V-2x6

x1 = 1x (650mm)

Weight

3.02KG(Net) / 3.42KG(Gross)

Dimension

333 x 197 x 122mm (13.1 x 7.63 x 4.72")

Warranty

10 years
