Exterior Color

White

CPU Socket

Intel® LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156

AMD® AM5 / AM4

Radiator Material

Aluminum

Radiator Dimensions

394 x 119.6 x 27.2 mm (15.5 x 4.7 x 1.1 inch)

Tube Length

400 mm

Waterblock Dimensions

153.5 x 84.2 x 83.9 mm (6 x 3.3 x 3.3 inch)

Pump Profile

Addressable RGB

Pump Speed

2800 ±10% RPM

Pump MTTF

> 35,000 hours

Pump Noise Level

25 dBA (Max)

Pump Connector

3-Pin ARGB + 4-Pin PWM

Pump Rated Voltage

12 VDC

Pump Power Consumption

6 W

Fan Dimensions (L x W x H)

120 x 120 x 25 mm ​ (4.7 x 4.7 x 1 inch)

Fan Quantity

3 PCS

Fan LED Type

Addressable RGB

Fan Speed

650 ~ 1750 RPM ±10%

Fan Airflow

122.4 m³/h (71.9 CFM) (Max)

Fan Noise Level

27.2 dBA (Max)

Fan Air Pressure

1.86 mmH₂O (Max)

Fan Bearing Type

LDB

Fan MTTF

>40,000 Hours

Fan Connector

7-Pin PWM + ARGB

Fan Rated Voltage

12 VDC

Fan Rated Current

0.26 A

Fan Safety Current

0.37 A

Fan Power Consumption

3.12 W

Display Module

Display Type: TFT LCD

DispIay Area (Resolution): 4 inch (480*480)

Luminance: 300 cd/m²

Rated VoItage: 5 VDC

Rated Current: 0.3 A

Safety Current: 0.5 A

Connector: USB 2.0 9PIN

Refresh Rate: 30Hz

Orientation: Software-MasterCenter adjustable

Warranty

5 Years

Note*

Price, feature and specifications are subject to change without notice
