Model

MAP-T6PN-225PW-CW

CPU Socket

Intel® LGA 1851 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156

AMD® AM5 / AM4

Color

White

Heat Sink Material

6 Heat Pipes/ Aluminum Fins

Fan

Size (mm): 120

Profile: Non LED

Quantity (pcs.): 2

Speed: 0 – 2400 RPM ± 10%​

Airflow (max.): 127.6 m3/h(75.2 CFM)

Pressure (max.): 3.63 mmH2O​

MTTF: > 200,000 hours​

Noise Level(max.):  30 dBA

Bearing: Loop Dynamic Bearing​

Power Connector: 4-Pin PWM​

Rated Voltage: 12 VDC​

Rated Current: 0.18 A​

Safety Current: 0.35 A​

Power Consumption: 2.16 W​

Dimension (L x W x H): 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch

Dimension

Product: 127 X 114 X 159 mm / 5.0 x 4.4 x 6.2 inch

Box: 23 x 19 x 16.5 cm / 9.06 x 7.48 x 6.5 inch

Weight

Net: 1.35 kg / 2.98 lb

Gross: 2.17 kg / 4.78 lb

Warranty

5 Years

Note*

Price, feature and specifications are subject to change without notice
