Model

MCB-CM694-KN5N-S00 (Steel)

SERIES

MasterBox Series

AVAILABLE COLOR

Black

SIZE

Mid Tower

MATERIALS

Steel, Plastic, Mesh

DIMENSIONS (L X W X H)

Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions)

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX, E-ATX

EXPANSION SLOTS

7

DRIVE BAYS

5.25" DRIVE BAYS = 2

2.5" / 3.5" DRIVE BAYS (COMBO) = 6 (3x drive cages)

2.5" DRIVE BAYS = 8 (2 + 6 combo)

I/O PANEL

2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic)

PRE-INSTALLED FANS

PRE-INSTALLED FANS - FRONT = 2x 120mm Fan (1200 RPM ± 200 RPM, 3 pin connector)

PRE-INSTALLED FANS - REAR = 1x 120mm fan (1200 RPM ± 200 RPM, 3 pin connector)

FAN SUPPORT

FAN SUPPORT - FRONT

3x 120mm / 2x 140mm (wo/ODD), 2x 120mm / 2x 140mm (w/ODD)

FAN SUPPORT - TOP

3x 120mm, 2x 140mm

FAN SUPPORT - REAR

1x 120mm

RADIATOR SUPPORT

RADIATOR SUPPORT - FRONT = 120mm*, 140mm*, 240mm*, 280mm**, 360mm** (*remove 2 out of 3 drive cages) (**remove 2 out of 3 drive cages & ODD cage)

RADIATOR SUPPORT - TOP = 120mm, 140mm, 240mm, 280mm, 360mm, (mount radiator below the bracket & fans above the bracket for maximum compatibility)

RADIATOR SUPPORT - REAR = 120mm

CLEARANCE

CLEARANCE - CPU COOLER = 171mm

CLEARANCE - GFX = 410mm/16.1", 350mm (with stabilizer), 280mm (with stabilizer + drive cage)

CLEARANCE - PSU = 276mm, 160mm (drive cage rear position)

DUST FILTERS

Top, Front, Bottom

POWER SUPPLY SUPPORT

Bottom mount, ATX PS2

SERIES

MasterBox Series

CABLE ROUTING

27-29mm

Warranty

2 Years

Note*

Price, feature and specifications are subject to change without notice.
