Product Number

MLY-D36M-A24PZ-R1

Exterior Color

Black

CPU Socket

Intel® LGA 1700 / 1200 / 1156 / 1155 / 1151 / 1150 / socket

AMD® AM5 / AM4 socket

Radiator Material

Aluminum

Radiator Dimensions

394 x 119.6 x 27.2mm (15.5 x 4.7 x 1.1 inch)

Pump Dimensions

88.3 x 83.6 x 65.7 mm (3.5 x 3.3 x 2.6 inch)

Pump MTTF

>210,000 Hours

Pump Noise Level

20 dBA (Max)

Pump Connector

4-Pin + SATA

Pump Rated Voltage

12 VDC

Pump Power Consumption

6.75 W

Fan Dimensions (L x W x H)

120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch

Fan Quantity

3 PCS

Fan LED Type

Addressable Gen 2 RGB

Fan Speed

0 ~2400 RPM ± 10%

Fan Airflow

127.6 m³/h (75.2 CFM

Fan Noise Level

30 dB(A)

Fan Pressure

3.63 (mmH2O)

Fan Bearing Type

Loop dynamic bearing

Fan MTTF

>200,000 hours

Fan Power Connector

4-Pin PWM

Fan Rated Voltage

12 VDC

Fan Rated Current

0.18A

Fan Safety Current

0.35A

RAM Clearance

N/A

Package dimension (L x W X H)

41.0 x 21.1 x 13.6 cm

Weight

Net: 2KG, Gross: 3.12KG

Warranty

6 years

Note*

Price, feature and specifications are subject to change without notice
