Product Number

MLX-D36M-A25SZ-L1

Color

Black

CPU Socket Support

Intel: Intel® LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156

AMD: AMD® AM5 / AM4

Radiator

Material: Aluminum

Dimension: 394 x 119.2 x 27 mm

Pump

Dimension: 92.5 x 87 x 39 mm

Profiles: Addressable GEN 2 RGB

Speed: 3400 ± 300 RPM

MTTF: > 210,000 hours

Noise Level (Max): 25 dB(A)

Rated Voltage: 12 VDC

Power Consumption: 3.84 W

Connector: 3-Pin ARGB + 4 Pin PWM

Tube

Length: 400 mm

Fan

Dimensions: 361 x 122 x 26.5 mm

LED Profiles: Addressable GEN 2 RGB

Quantity: 1 PC

Speed: 690 ~ 2500 RPM ± 15%

Air Flow (Max): 322.8 m³/h (190 CFM)

Air Pressure (Max): 3.61 mmH2O

MTTF: > 160,000 hours

Noise Level (Max): 38.5 dB(A)

Bearing: Loop dynamic bearing

Connector: 7-Pin PWM + ARGB

Rated Voltage: 12 VDC

Rated Current: 0.5 A

Safety Current: 0.8 A

Power Consumption: 6 W

LCD

Dimensions: 85.0 x 79.2 x 18.7 mm

Connector: USB Type-C to Motherboard 9pin

Screen Size: 2.1 inches / Diameter 53.3 mm

Resolution: 480 x 480 px

Luminance: 300 cd/m²

Refresh Rate: 60 Hz

Orientation: Software-MasterCtrl adjustable

Rated Voltage: 5 VDC

Rated Current: 0.3 A

Safety Current: 0.5 A

Power Consumption: 1.5W

Warranty

6 years

Note*

Price, feature and specifications are subject to change without notice
