- Model: NR100-ZNNN85-SL0
*T&C Apply
NCORE 100 MAX Bronze edition
NR100-ZNNN85-SL0
- High-end ITX design - At a volume of 15.7 liters and with premium
Cooler Master cooling and power solutions, the NCORE 100 MAX satisfies all your
performance and space-saving needs.
- Ultra small footprint - NCORE100 Max footprint is 212*155mm (3slots
mode) , which is 15.3% smaller than Mac mini . perfect choice to save your desk
space
- Support for the latest GPUs - Includes support for high performance,
triple-slot GPUs up to 337mm in length and 180mm in height, with included
ATX3.0 power cables and a vertical mount design. The PCIe slot can be adjusted
for even larger GPU up to 357mm length.
- Extendable width - Extendable width from 155mm to 172mm
allows for 3.9 GPU slot thick RTX 4090 compatibility or 3 slot width for a
super-small form factor.
- Premium aluminium paneling - An anodized aluminium shell makes
the NCORE 100 MAX stand out as a desktop work of art.
- Tailor-made power solution - Cooler Master’s V SFX Gold 850W
ATX 3.0 PSU covers all your power needs and comes with custom length cables.
- High performance cooling solution - A custom thick radiator
120mm AIO cooling solution works well with the latest i9 and R9 CPUs and
features both AMD AM4 and Intel LG1700 sockets.
- Tool-less technology - The fully tool-less opening mechanism
allows you easily access to every part of the NCORE 100 MAX.
- PCIe 4.0 cable Included - A specially tailored PCIe 4.0
cable enables extra easy installation.
Specification | |
Product
Name | NCORE
100 MAX Bronze edition |
Model
Number | |
Color | Bronze |
Materials | Exterior:
Steel, Plastic, Aluminum Left
Side Panel: Aluminum |
Dimensions (L
x W x H) | Incl.
Protrusions: 155mm x 212mm x 481mm (Normal mode) / 172mm x 212mm x 481mm
(Expansion mode) Excl.
Protrusions 155mm x 212mm x 457mm / 172mm x 212mm x 457mm Volume
(Liters Incl. Protrusions): 15.80L / 17.54L |
Motherboard
Support | ITX |
Expansion
Slots | 3 x
PCIe Slot mounting |
Drive
Bays | 5.25“
ODD: N/A 3.5”
HDD: N/A 2.5”
SSD: 1 |
I/O
Panel | USB
Ports: USB 3.2 Gen1 Type A x 2, USB 3.2 Gen2 x 2 Type C x 1 Audio
In / Out 3.5mm: Audio combo x 1 |
Included
Riser Cable | 240mm
PCIe 4.0 x16 x 1 |
Included
CPU Cooling Solution | 120mm
Radiator with 38mm thickness x 1 (Custom PWM fan max.2400RPM
) |
Included
Power Supply Unit | V SFX
Gold 850W ATX3.0 |
Pre-installed
Fan(s) | 120mm
SickleFlow PWM fan x1(max. 1800RPM) |
Clearances | CPU
Cooler: 48mm Power
Supply: 100mm RAM:
48mm Graphics
Card: 337mm x 62mm x 180mm (Normal,
3.0 Slot thick) 357mm x 79mm x 180mm (Expansion,
3.9 Slot thick) (Maximum space including GPU
power connector) |
Cable Routing | Behind
MB Tray: 11mm |
Dust
Filters | Side
panels |
Power
Supply Support | SFX |
Warranty | 2 years
(Case), 2 years (Thermal Solution), 10 years (Power Delivery) |
Note* | Price, feature and specifications
are subject to change without notice. |
