- Model: NR200P-MCNN85-SL0
NR200P MAX
NR200P-MCNN85-SL0
- The First of Cooler Master’s MAX Series – Max out your PC
performance with Cooler Master’s new MAX Series, complete with custom thermal
and power delivery solutions. Tailor-made to provide versatile hardware
compatibility, as well as providing ample clearance for the largest, widest
graphics cards on the market, MAX delivers ready-to-go building platforms for
high-performance systems.
- Cooler Master’s Expertise At Its Finest – NR200P MAX is a
masterpiece integrating Cooler Master’s expertise in the thermal, power
delivery and mechanical design, designed for unstoppable performance and
capable of satisfying the most power-hungry systems.
- SFF Building Refined – Get a head start in building your SFF
PC! Taking up only 18 liters of volume, the NR200P MAX takes the difficulty and
hassle of cable management out of small form factor PC building.
- Luxurious, Out-of-the-Box Solution – A time efficient,
ready-made solution for PC enthusiasts who place utmost value on their PC
performance. NR200P MAX saves users from hours upon hours of tedious research
with guaranteed hardware compatibility.
|
Specification |
|||
|
Product Name |
MasterBox NR200P MAX |
||
|
Product Number |
NR200P-MCNN85-SL0 |
||
|
Exterior Color |
Black / Grey |
||
|
Materials |
Exterior: SGCC Steel, Mesh, ABS Plastic Left Side Panel: Tempered Glass x1, Steel x1 |
||
|
Dimensions (L x W x H) |
Incl. Protrusions: 377 x 185 x 292mm Excl. Protrusions: 361 x 185 x 274mm |
||
|
Volume |
18.30L |
||
|
Motherboard Support |
Mini-ITX, Max. size: 170 x 180mm |
||
|
Expansion Slots |
3 |
||
|
Drive Bays |
5.25“ ODD: 0 3.5” HDD: 1 (Max. 2) 3.5” / 2.5” Combo: 1 2.5” SSD: 2 (Max. 3) |
||
|
I/O Panel |
USB Ports: 2 x USB 3.2 Gen 1 (USB 3.0) Audio In / Out: 1x 3.5mm Headset Jack (Audio + Mic) |
||
|
Fan Support |
Top: 2 x 120mm / 2 x 140mm Bottom: 1 x 120mm (max 15mm, with 3.5” HDD at the bottom)
/ 2 x 120mm (max 15mm, w/o 3.5” HDD at the bottom) |
||
|
Radiator Support |
Top: 240mm/ 280mm |
||
|
Clearances |
CPU Cooler: 67mm Power Supply: 130mm Graphics card: L: 336mm (incl. power connector), H: 160mm
(incl. power connector), W: 75mm (triple slot) |
||
|
Dust Filters |
Bottom, Left, Right, Top Panels |
||
|
Included Accessories |
35mm PCIe 4.0 x16 riser cable x1 (Excluding plastic ends.) |
||
|
Net weight |
7.7kg |
||
|
Gross weight |
9.0kg |
||
|
Carton dimension (L x W x H) |
355 x 293 x 458mm |
||
|
Power Supply Support |
SFX, SFX-L |
||
|
Included Power Supply Unit |
|||
|
Model: |
V850 SFX GOLD 850 Watt |
||
|
PFC |
Active PFC |
||
|
Modular |
Fully |
||
|
Input Voltage |
100-240V |
||
|
Input Current |
12~6A |
||
|
Input Frequency |
50~60Hz |
||
|
Dimensions (L x W x H) |
100 x 125 x 63.5mm |
||
|
Form Factor |
SFX |
||
|
Fan Size |
92mm |
||
|
Fan Bearing |
FDB |
||
|
Efficiency |
90% @ Typical Load |
||
|
80 PLUS Rating |
80 PLUS Gold |
||
|
ErP 2014 Lot 3 |
Yes |
||
|
Operating Temperature |
0~50°C |
||
|
Power Good Signal |
100-500ms |
||
|
Hold Up Time |
16ms |
||
|
MTBF |
>100,000 hours |
||
|
Protections |
OVP / OPP / SCP / OCP / UVP / OTP / Surge and Inrush
Protection |
||
|
Regulatory |
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB |
||
|
Included CPU Cooling Solution |
|||
|
Type |
280mm radiator with Gen 3 Cooler Master Pump / CPU Block |
||
|
Exterior Color |
Black |
||
|
CPU Socket |
Intel: LGA 2066 / 2011-v3 / 2011 / 1200 / 1151 / 1150 /
1155 / 1156 / 1700 AMD: AM4 / AM3+ / AM3 / AM2+/ AM2 / FM2+ / FM2 / FM1 |
||
|
Radiator |
Material: Aluminum Dimensions (L x W x H): 318 x140 x 27.2 mm (10.9 x 4.7 x
1.1 inch) |
||
|
Pump |
Dimensions (L x W x H): 79.9 x 76 x 47 mm (3.15 x 3
x 1.85inch) MTTF (Hours): 70,000 hours Noise Level (dBA): <10dBA Connector: 3-Pin Rated Voltage (VDC): 12 Power Consumption (W): 2.36 W |
||
|
TDP (W) |
230 |
||
|
Included Fans |
|||
|
Type |
140mm SickelFlow PWM |
||
|
Dimensions (L x W x H) |
140 x 140 x 25 mm (5.5 x5.5 x 1 inch) |
||
|
Quantity (pcs) |
2 |
||
|
LED Type |
Non-LED |
||
|
Speed (RPM) |
650~1400RPM ± 5% |
||
|
Airflow (CFM) |
67 CFM (Max) |
||
|
Noise Level (dBA) |
10~27 dBA |
||
|
Pressure (mm H2O) |
2.25 mm H₂O (Max) |
||
|
Life Expectancy (Hours) |
160,000 hours |
||
|
Power Connector |
4-Pin |
||
|
Rated Voltage (VDC) |
12 |
||
|
Rated Current (A) |
0.15A |
||
|
Included Splitter Cable |
2to1 4pin PWM splitter |
||
|
Warranty |
2 years (Case) 2 years (Thermal Solution) 10 years (Power Delivery) |
||
|
Note* |
Price, feature and specifications
are subject to change without notice. |
||
