Model Number

MF600M-KGNN-S01

Exterior Color

Black

Materials

Exterior: SGCC Steel, Aluminum

Side panel (Right / Left): Tempered Glass / Aluminum

Dimensions (L X W X H)

531 x 261 x 544mm (Incl. Protrusions),

514 x 244 x 514 mm (Excl. Protrusions)

Volume

73.6 L (Liters Incl. Protrusions)

Motherboard Support

Mini-ITX, Mini-DTX, Micro-ATX, ATX , E-ATX*, SSI-CEB* ​(*Conditional Support)

Expansion Slots

8

Drive Bays

5.25" Drive Bays: 0

3.5" Drive Bays: 0

2.5" / 3.5" Drive Bays (Combo): 2

2.5" Drive Bays: 3

I/O Panel

2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2x2 Type C

1x 3.5mm Headset Jack (Audio+Mic)

Pre-Installed Fans

Front: 2x SickleFlow 200 ARGB

Rear: 1x SickleFlow 120 ARGB

Fan Support

Front: 3x 120mm, 3x 140mm, 2x 180mm, 2x 200mm

Top: 3x 120mm, 2x 140mm, 2x 180mm, 1x 200mm

Rear: 1x 120mm

Side: 3x 120mm, 3x 140mm

Radiator Support

Front: 120 / 140 / 240 / 280 / 360 / 420 mm

Top: 120 / 140 / 240 / 280 / 360 / 420 mm (Up to 420mm if I/O module is moved to the front panel)

Rear: 120 mm

Side; 240 / 280 / 360 / 420 mm

Clearances

CPU Cooler: 190 mm

PSU: 235 mm

Graphics Card: L: 485 mm (incl. power connector), H: 190 mm (incl. power connector)

Cable Routing

Behind Motherboard Tray: 43 mm

Dust Filters

Top, Front, Bottom, Right side panel

Power Supply Support

ATX

Included Accessories

GPU Support Bracket / ARGB PWM Hub

Warranty

2 Years

Note*

Price, features and specifications are subject to change without notice.
