- Model: CGR-8M02B
QBX (CGR-8M02B)
Size Does Matter
The most advanced compact case of the market is here. COUGAR QBX comes here to conquer the world with three big weapons within its compact body: Its dimensions, its expansion potential and its unrivalled cooling.
Compact
QBX's 178 x 291 x 384 mm/7.01 x 11.46 x 15.12 (in) make it a
highly compact case.
Gamers no longer need enormous desks with lots of space to install high-end
gaming components
in order to enjoy new generation games.
Expandable: Powerful Graphics
The newest FPS?
Sure.
New generation 4K video games?
Of course.
With QBX Kaze, you gain access to new generation games in all their glory.
Expandable: Massive Storage + ODD
Up to 5 Storage Drives (1 x 3.5¨ HDD + 4 x 2.5¨ SSD/HDD)
Access to CD, DVD, Blu-ray and other Disk Formats. Nobody likes those situations
in which you need to uninstall a game to be able to install another one.
To prevent this, QBX supports enormous amounts of storage so that you can put
all your games, music, movies and whatever you want inside it.
The Best Cooling of Its Class
QBX comes with the best cooling of any case of its class. With a maximum of seven fans (from 80mm to 120mm) and compatibility with up to 240mm radiators for water cooling solutions, QBX's Pro-cooling design (including an independent power supply airflow) provides the best defence against overheating.
|
Specification |
|
|
Product Name |
QBX |
|
Model No. |
CGR-8M02B |
|
Case Form Factor |
Mini-ITX Case |
|
Motherboard Type |
Mini-ITX |
|
Dimensions (WxHxD) |
7.01 x 11.46 x 15.12 (in) |
|
Optical Disk Drive (ODD) Type |
Supports ONLY Slot Loading Slim ODD |
|
3.5" Internal Drive Bay (HDD) |
1 |
|
2.5" Drive Bay (HDD/SSD) |
4 |
|
Expansion Slots |
2 |
|
I/O Panel |
2 x USB3.0/HD audio |
|
Cooling System Max. Supported Installation: |
Front = 80mm fan x 1 (optional) Top = 120mm fans x 2 (optional) Rear = 90mm fan x 1 (pre-installed) Bottom = 120mm fans x 2 (optional) Left Side = 120mm fan x 1 Or 240mm radiator with a single 120mm fan or 120mm radiator with a 120mm fan |
|
Cable Management System |
Cable feedthrough on the motherboard tray for easy routing and hiding of cables. |
|
Fan Filter (Cleanable) |
1 x Bottom Filter (pre-installed and removable) |
|
Water Cooling Support |
Left Side：240mm radiator with a single 120mm fan |
|
Max. Graphics Card Length |
350mm (Support for High-End Graphics Cards) |
|
Max. CPU Cooler Height |
105mm |
|
PSU |
PS2 ATX Type |
|
Max. PSU Length |
140 mm / 5.5 (in) |
|
Compatible PSU |
Supports the following COUGAR PSU series: |
|
Warranty |
1 Year |
|
Note* |
Price, feature and specifications
are subject to change without notice. |
