Model

R-AS500-BKNLMN-G

Application For

Intel: LGA2066/2011-v3/2011/1700/1200/1151/1150/1155

AMD: AM5/AM4

Product Dimensions

142×98×164 mm(L×W×H)

Heatsink Dimensions

140×49×159 mm(L×W×H)

Net Weight

1030 g

Heatpipe

Ø6 mm×5 pcs

Fan Dimensions

140×140×25 mm(L×W×H)

Fan Speed

500~1200 RPM±10%

Fan Airflow

70.81 CFM

Fan Air Pressure

1.14 mmAq

Fan Noise

≤29.2dB(A)

Overall Noise

≤26 dB(A)

Fan Connector

4-pin PWM

Bearing Type

FDB

Fan Rated Voltage

12 VDC

Fan Rated Current

0.11 A

Fan Power Consumption

1.32 W

LED Type

Addressable RGB LED

LED Connector

3-pin(+5V-D-G)

LED Rated Voltage

5 VDC

LED Power Consumption

1.4 W

Warranty

1 Year

Note*

Price, feature and specifications are subject to change without notice.
