Application For

Intel: LGA1851/1700/1200/1151/1150/1155

AMD: AM5/AM4

Model

R-LE360-BKAMMC-G-2

Net Weight

1632 g

Radiator Dimensions

402×120×27 mm(L×W×H)

Radiator Material

Aluminum

Tube length

410 mm(L×W×H)

Pump Dimensions

91×78×65 mm(L×W×H)

Pump Speed

2500~3400 RPM±10%

Pump Connector

4-pin PWM

Pump Rated Voltage

12 VDC

Pump Rated Current

0.29 A

Pump Power Consumption

3.48 W

Fan Dimensions

120×120×25 mm(L×W×H)

Fan Speed

500~2100 RPM±10%

Fan Airflow

75.89 CFM

Fan Air Pressure

2.53 mmAq

Fan Noise

≤31.6 dB(A)

Fan Connector

4-pin PWM

Bearing Type

Hydro Bearing

Fan Rated Voltage

12 VDC

Fan Rated Current

0.17 A

Fan Power Consumption

2.04 W

LED Type

Addressable RGB LED

LED Connector

3-pin(+5V-D-G)

LED Rated Voltage

5 VDC

LED Power Consumption

2.8 W（PUMP）/ 3.15 W（FAN×3）

Warranty

3 Years

Note*

Price, feature and specifications are subject to change without notice.
