Model No.

R-PK750D-FA0B-UK

Type

ATX12V V2.4

Product Dimensions

150×140×86mm (W x L x H)

80PLUS Certifications

Bronze

Fan Size

120mm

Fan Bearing

Hypro Bearing

Topology

Active PFC+DC to DC

Capacitors

Taiwan capacitor

Power Good Signal

100-150ms

Hold Up Time

≥16ms(80% Load)

Efficiency

≥85% Under Typical Load(50% Loading)

Protection

SCP,OPP,OTP,OVP,OCP,UVP

Operation Temperature

0 - 40 °C

Regulatory

CB/CE/FCC/CAN ICES-003(B)/NMB-003(B)/ TUV-RH/CCC/UKCA/EAC/RCM/BIS

Erp Regulation

ErP 2013

MTBF

100,000 Hours

Connector

Main Power Connector 24 (20+4)Pin: 1

EPS 12V Connector 8 (4+4)Pin: 2

PCI-E (6+2)Pin: 4

SATA : 8

4Pin Peripheral: 4

Warranty

5 Years

Note*

Price, feature and specifications are subject to change without notice.
