- Model: R-PL750D-FC0B-IN-V2
PL750D
R-PL750D-FC0B-IN-V2
The PL750D updates
DeepCool non-modular PSUs with a 12VHPWR cable and brings them into compliance
with INTEL's ATX3.0 standard. These units are 80 PLUS Bronze-verified, come
with a 120mm hydro-bearing fan, and will provide stable power for years to
come.
Specification | |
Model No. | R-PL750D-FC0B-IN-V2 |
Cables | Main Power
Connector (20+4)Pin x 1 – 1PCS CPU(4+4)Pin x 1– 2PCS PCI-E(6+2)Pin x 1
– 1PCS PCI-E(6+2)Pin x 2
– 1PCS 12V-2x6(16Pin) x
1 – 1PCS SATA x 4 + 4Pin
Peripheral x 1 – 2PCS |
Type | ATX12V V3.0 |
Product Dimensions | 150×140×86mm (W x L x H) |
Efficiency certification | 80Plus Bronze |
Fan Size | 120mm |
Fan Bearing | HYB(Hydro Bearing) |
Topology | Active PFC+DC to DC |
Capacitors | Chinese Electrolytic Capacitors |
Power Good Signal | 100-150ms |
Hold Up Time | ≥16ms |
Efficiency | ≥85% Under Typical Load(50% Loading) |
Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
Operation Temperature | 0 - 40℃ |
Regulatory | CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH |
Erp Regulation | ErP 2014 |
Environment Protection | WEEE/中国 RoHS/Triman/P65 |
MTBF | 100,000 Hours |
Warranty | 5 Years |
Note* | Price,
feature and specifications are subject to change without notice. |
