Socket Compatibility

Intel: LGA1851/1700/1200/115X

AMD: AM5/AM4

P/N

R-AK400G2-BKNNMN-GJD-1

Product Dimensions

132×92×156 mm(L×W×H)

Heatsink Dimensions

130×92×151 mm(L×W×H)

Net Weight

958 g

Heatpipe

Ø6 mm×4 pcs

Fan Dimensions

120×120×25 mm(L×W×H)

Fan Speed

2200±10% RPM(max)

Fan Airflow

63.4 CFM

Fan Air Pressure

3.33 mmAq

Fan Noise

≤31.45 dB(A)

Fan Connector

4-pin PWM

Bearing Type

Hydro Bearing

Fan Rated Voltage

12 VDC

Fan Rated Current

0.25 A

Fan Power Consumption

3 W

Display Module Rated Current

0.13 A±10%

Display Module Rated Voltage

5 VDC

Display Module Power Consumption

0.65 W

Display Area

29x39 mm

Warranty

3 Years

Note*

Price, feature and specifications are subject to change without notice.
