- Model: FD-W-2-S2802
Celsius+ S28 Prisma
Celsius+ takes AIO water cooling to a new level with an
ARGB-accented pump face, a fully redesigned block and an upgraded on-radiator
PWM fan hub with ARGB support.
- Tinted glass pump face with backlit logo and ARGB LED
effects
- Articulating elbow fittings make tubes easier to route and
reduces tension on the pump
- Backed by a 5-year warranty for extended peace of mind
The brilliance of prisma
- Prisma ARGB PWM fans deliver outstanding airflow with
brilliant lighting effects
- Specially designed fan blades and outer ring produce a
uniform glow
- Optimized fan geometry balances airflow with extra emphasis
on static pressure
- Trip Wire technology reduces blade turbulence
- LLS (Long Life Sleeve) fan bearings provide silent operation
with a long lifespan
Get the balance right
Our intelligent auto mode dynamically adjusts the fan and
pump speeds for optimized silent performance – and a simple twist of the pump
face changes to PWM mode for full user control
Tidier through technology
ARGB-enabled PWM hub places all fan connections directly on
the radiator for a clutter-free installation
Forget the thermal paste
With the Celsius+, the thermal paste is pre-applied to
ensure a mess-free installation
|
Specification |
|
|
General Specifications |
Sockets supported
(Intel) : 1200, 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, 2066 Sockets supported (AMD)
: AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+, TR4 (via included bracket in AMD
Threadripper box) Coldplate material :
Copper Thermal paste :
Pre-applied Tube length : 400 mm Tube material :
Low-permeability rubber with braided nylon sleeve Fittings, block side :
Articulating 90-degree elbow Fittings, radiator side
: Straight rotary Fan control : Dual mode
(Auto/PWM) Note: The Celsius+ is
NOT compatible with the Adjust R1 |
|
Fan Specifications |
Fan type : Prisma AL-14
PWM ARGB Rotational speed : 500
– 1700 RPM Bearing : LLS PWM control : Yes Acoustical noise (full
speed) : 34.1 dBA Maximum air flow :
103.9 CFM Maximum static pressure
: 2.38 mm H2O Input voltage : 12V DC Maximum input current :
0.18A MTBF : 100,000 hours |
|
Pump specifications |
Rotational speed :
800-2800 RPM in normal use, 3500 RPM during thermal protection mode that
activates if liquid temperature is over 60°C Bearing type : Ceramic
bearing and shaft PWM control : Yes Acoustical noise (full
speed) : 20 dBA Maximum pressure : 14.4
kPa / 1.46 mm H2O /2.0 PSI Input voltage :
12V DC Input current (without
fans) : 0.36A MTTF : 50,000 hours Block height : 45 mm Block measurements
(with fittings) : 86 x 75 mm Block diameter (main
block body) : 62 mm |
|
Radiator Specification |
Dimensions : 143 x 30 x
324 mm Housing material :
Aluminum Fin material : Aluminum Fan screw threads :
6-32 |
|
Others |
Package contents :
Celsius+ S28 unit, 2 x 140 mm fans, User manual, Mounting hardware for all
listed sockets, Fan and radiator mounting screws Product code : FD-W-2-S2802 |
|
Warranty |
5 Years |
|
Note* |
Price, feature and specifications are subject to change without notice |
