Form Factor

M.2 2280

Interface

PCIe 4.0 NVMe

Capacities

2048GB

Controller

Phison E18

NAND

3D TLC

Sequential read/write

7,000/7,000MB/s

Random 4K read/write

up to 1,000,000/1,000,000 IOPS

Total Bytes Written (TBW)

1.6PBW

Power consumption

5mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write

Storage temperature

-40°C~85°C

Operating temperature

0°C~70°C

Dimensions

80mm x 22mm x 3.5mm

Weight

9.7g

Vibration operating

2.17G peak (7-800Hz)

Vibration non-operating

20G Peak (20-1000Hz)

MTBF

1,800,000 hours

Warranty

Limited 5-year warranty with free technical support

Note*

Price, feature and specifications are subject to change without notice.
