Form factor

M.2 2280

Interface

PCIe 5.0 x4 NVMe

Capacities

1024GB

Controller

SM2508

NAND

3D TLC

DRAM cache

Yes

DirectStorage supported

Yes

Sequential read/write

up to 14,200/11,000MB/s

Random 4K read/write

up to 2,200,000/2,150,000 IOPS

Total Bytes Written (TBW)

1.0PBW

Power consumption

0.27W avg / 6.6W @ 14.2G / 6.6W (MAX)

Storage temperature

-40°C~85°C

Operating temperature

0°C~70°C

Dimensions

80mm x 22mm x 2.3mm

Weight

7.3g

Vibration operating

2.17G peak (7-800Hz)

Vibration non-operating

20G Peak (20-1000Hz)

MTBF

2,000,000 hours

Warranty

Limited 5-year warranty with free technical support

Note*

Price, feature and specifications are subject to change without notice.
