Pump

Pump model: Asetek Emma V2

Pump block height: 70 mm

Motor type (phases): Three phase

Impeller type: Centrifugal (closed)

Bearing: Ceramic sleeve and shaft

Rated voltage: 12 V

Starting voltage: 9.5 V

Max. operating voltage: 13.2 V

Input power (max): 6 W

Input power (typical): 2 W

Input current (max): 1.7 A

Input current (typical): 0.5 A

Max. rotational speed (manual mode): 3400 rpm

Max. rotational speed (balanced mode): 2600 rpm

Max. rotational speed (quiet mode): 2100 rpm

Rotational speed @ 20% PWM: 750 rpm

Rotational speed @ 0% PWM: 750 rpm

Max. acoustical noise (manual mode): 14.9 dB(A)

Max. acoustical noise (balanced mode): 7.8 dB(A)

Max. acoustical noise (quiet mode): <5 dB(A)

Cable length: 500 mm

Connector type: 4-pin PWM

Cold plate material: Copper CU1100 (99.95% high-purity)

Cold plate size: 55.5 x 55.5 mm

Construction: Skived fin micro channels

Mounting system: SecuFirm2+

Mounting hole pitch: 78 mm

Pump noise absorber: NL-PNA1

Auxiliary cooling fan: Optional (NL-ACF1)

Coolant specifications

Composition: 22% propylene glycol - 78% water

Inhibitors: Anti-freeze, Anti-corrosion, Antibiological

Compatibility: Non-toxic, Electrically conductive

Tube specifications

Material: EPDM (braided)

Tube length: 410 mm

Outer diameter: 12.5 mm

Inner diameter: 7 mm

Min. bend radius: 26 mm

Socket compatibility

AM5, AM4, LGA1700, LGA1851, LGA1954

Radiator

Form factor: 360 mm

Material (fins): Aluminium

Material (tubes): Aluminium

Material (frame): Steel

Fins per inch (FPI): 20

Radiator size: 399.5 x 120 x 30 mm

Fan configuration: 3x 120x120x25 mm

Screw threads: UNC 6-32

Operating temperature

2°C to 50

Fan: NF-A12x25 G2 PWM

Size (Form factor): 120 x 120 x 25 mm (square)

Speed range: 0 – 1800 rpm

Airflow (max.): 107.3 m³/h (63.15 CFM)

Acoustical noise (max.): 22.5 dB(A)

Static pressure (max.): 3.14 mm H₂O

Rated voltage: 12 V

Connector: 4-pin

Colour: Brown

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
