Socket compatibility

AMD AM5, AM4 and Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150

Dimension (without fan)

168(H) x 150(W) x 127(D) mm

Dimension (with fan)

168(H) x 150(W) x 152(D) mm

Weight (without fan)

1180g

Weight (with fan)

1525g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR

228

Fan compatibility

140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 (optional NA-SFC12 fan clips required)

Scope of delivery

2x NF-A14x25r G2 PWM premium fan

2x NA-RC16 Low-Noise Adaptor (L.N.A.)

NA-YC1 4-pin PWM splitter cable

NT-H2 high-grade thermal compound

NA-TPG1 thermal paste guard for AM5

NA-CW1 cleaning wipe

SecuFirm2+™ multi-socket mounting system

4x NM-ISW1 shim washers for LGA1700

NM-SD1 Torx® T20 screwdriver

Noctua metal case-badge

FAN Specification

Model: 2x NF-A14x25r G2 PWM

Bearing: SSO2

Max. rotational speed (+/- 10%): 1500 RPM

Max. rotational speed with L.N.A. (+/- 10%): 1250 RPM

Max. airflow: 155.6 m³/h

Max. airflow with L.N.A.: 127.1 m³/h

Max. acoustical noise: 24.8 dB(A)

Max. acoustical noise with L.N.A.: 19.7 dB(A)

Blade geometry: Progressive-Bend impeller

Acoustical noise: 24.8 dB(A)

Input power (max.): 2.28 W

Voltage range: 12 V

MTTF: > 150.000 h

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
