Amplified Performance for Professionals The NVIDIA RTX™
A6000, built on the NVIDIA Ampere architecture, delivers everything designers,
engineers, scientists, and artists need to meet the most graphics and
compute-intensive workflows. The RTX A6000 is equipped with the latest
generation RT Cores, Tensor Cores, and CUDA® cores for unprecedented rendering,
AI, graphics, and compute performance. Certified with a broad range of
professional applications, tested by leading independent software vendors
(ISVs) and workstation manufacturers, and backed by a global team of support
specialists, NVIDIA RTX is the visual computing solution of choice for
demanding enterprise deployments.
Specification | |
GPU Memory | 48 GB GDDR6 |
Memory interface | 384-bit |
Memory bandwidth | 768 GB/s |
Error-correcting code (ECC) | Yes |
NVIDIA Ampere architecture-based CUDA Cores | 10,752 |
NVIDIA third-generation Tensor Cores | 336 |
NVIDIA second-generation RT Cores | 84 |
Single-precision performance | 38.7 TFLOPS |
RT Core performance | 75.6 TFLOPS5 |
Tensor performance | 309.7 TFLOPS |
NVLink | Connects two NVIDIA RTX A6000 GPUs |
NVLink bandwidth | 112.5 GB/s (bidirectional) |
System interface | PCI Express Gen 4 x 16 |
Power Consumption | Total board power: 300 W |
Thermal Solution | Active |
Form Factor | 4.4” (H) x 10.5” (L) Dual Slot, full height |
Display Ports | 4x DisplayPort 1.4a |
Max simultaneous displays | 4x 4096 x 2160 @ 120 Hz, 4x 5120 x 2880 @ 60 Hz, 2x 7680 x 4320 @ 60 Hz |
Power connector | 1x 8-pin CPU |
Encode/decode engines | 1x encode, 2x decode (+AV1 decode) |
Graphics APIs | DirectX 12.07, Shader Model 5.17, OpenGL 4.68, Vulkan 1.18 |
Compute APIs | CUDA, DirectCompute, OpenCL™ |
Virtual GPU (vGPU) Software Support | NVIDIA vPC/vApps, NVIDIA RTX Virtual Workstation, NVIDIA
Virtual Compute Server |
vGPU profiles supported | 1 GB, 2 GB, 3 GB, 4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB,
48 GB |
VR Ready | Yes |
Warranty | 3 Year |
Note* | Price, feature and specifications
are subject to change without notice. |
| GPU Chipset | NVIDIA Quadro |
| GPU Series | RTX A6000 |
| Architecture | Ampere |
| Render Units | Shading Units: 10752 CUDA, TMUs: 336, ROPs: 112, SM Count: 84, RT Cores: 84, Tensor Cores: 336 |
| Clock Speeds | Boost Clock: 1800 MHz, Base Clock: 1410 MHz, Memory Clock: 2000 MHz |
| Memory Capacity & Type | 48 GB GDDR6 |
| Memory Interface & Bandwidth | 384 bit, 768 GB/s |
| Bus Standard | PCIe Version 4.0 x16 |
| Display Outputs | Display Port: 1.4a x4 |
| Slot & Cooling Solution | Dual Slot - Single Fan |
| Power Requirments | TDP: 300 W, Power Connectors: 8-Pin CPU x1 |
