Model number

RL-KR36E-B1

Color

Black

Water Block

Dimensions: Diameter: 81.9mm H: 59.5mm

Material (Block): Copper

Material (Housing): Plastic

Pump

Motor Speed: 800 – 2,800 ± 300RPM

Power: 12V DC, 0.3A

Radiator

Dimensions: 121 x 394 x 27mm

Material: Aluminum

Tube

Length: 400mm

Material: Ultra-low Evaporation Rubber with Nylon Braided Sleeve

Cap

Material: Aluminum, Plastic

Display Orientation: Software adjustable Default, +90, +180, and -90 Degrees

Display Panel Active Area: 2.36” (60mm) diameter

Display Color: 24-bit true color LCD

Display Resolution: 640 x 640 px

Display Brightness: 690 cd/m²

Display Panel Type: TFT-LCD (Wide Viewing Angle)

Fan(S)

Model: F120 RGB Core Fans

Quantity: 3

Dimension: 120 x 120 x 26mm

Speed: 500-1,800 ± 180 RPM

Airflow: 78.86 CFM

Air Pressure: 2.57 mm H2O

Noise: 33.88 dBA

Bearing: Fluid Dynamic Bearing

Power Consumption: 12 V DC, 0.2 A, 2.4 W

Fan Connector: 4-pin PWM

Life: 60,000 hours / 6 Years

Limited Warranty: 6 Years

RGB Controller

Dimensions: 63.2 x 53.2 x 12.8mm

Weight: 52.8g

Mounting: Magnet and 3M Dual Lock

Connection Cables: 1x USB 2.0 internal connector 1x SATA power cable

Input Connector: 12V DC / 2.6A

RGB Lighting Channels: 3

Output Channel Voltage: 5V DC

NZXT RGB Channel Output LED Qty.: Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels

Compatible Socket & CPU

Intel: Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron

AMD: AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper

Inside the Box

Kraken Elite 360 RGB: 1

F120 RGB Core fan: 3

Installation Accessories: 1

RGB Controller: 1

Breakout cable set: 1

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
