MODEL

MPY-7501-SFHAGV

ATX VERSION

SFX 12V Ver. 3.42

PFC

Active PFC

INPUT VOLTAGE

90-264V

INPUT CURRENT

10-5A

INPUT FREQUENCY

47-63Hz

DIMENSIONS (L X W X H)

100 x 125 x 63.5 mm

FAN SIZE

92mm

FAN BEARING

FDB

EFFICIENCY

90% @ Typical Load

80 PLUS RATING

80 PLUS Gold

ERP 2014 LOT 3

Yes

OPERATING TEMPERATURE

0-50°C

POWER GOOD SIGNAL

100 - 500 ms

HOLD UP TIME

16ms

MTBF

>100,000 Hours

PROTECTIONS

OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection

REGULATORY

TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB

ATX 24-PIN CONNECTORS

1

EPS 4+4 PIN CONNECTORS

1

EPS 8 PIN CONNECTOR

1

SATA CONNECTORS

8

PERIPHERAL 4-PIN CONNECTORS

4

PCI-E 6+2 PIN CONNECTORS

4

SERIES

V Gold Series, V SFX Gold Series

80 PLUS

Gold

MODULAR

Full Modular

WATTAGE

500 to 750W

Warranty

10 Years

Note*

Price, feature and specifications are subject to change without notice
