CPU

Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors 1

Processor socket LGA1700

Please go to www.msi.com to get the newest support status as new processors are released.

Chipset

Intel® H610 Chipset

Memory

2x DDR4 memory slots, support up to 64GB 1

Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)

Supports Dual-Channel mode

Supports non-ECC, un-buffered memory

Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

1x PCIe x16 slot (From CPU)

Supports up to PCIe 4.0 x16

1x PCIe x1 slot (From H610 chipset)

Supports PCIe 3.0 x1

Onboard Graphics

1x HDMI™ 1.4 with HDR port, supporting a maximum resolution of 4K 30Hz

1x VGA port, supporting a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

Available only on processors featuring integrated graphics.Graphics specifications may vary depending on the CPU installed.

Storage

4x SATA 6Gb/s ports (From H610 chipset)

1x M.2 slot (Key M) (from CPU)

Supports up to PCIe 3.0 x4

Supports 2242/ 2260/ 2280 storage devices

USB

USB 3.2 PORTS (FRONT): 2(Gen 1, Type A)

USB 3.2 PORTS (REAR): 2(Gen 1, Type A)

USB 2.0 PORTS (FRONT): 4

USB 2.0 PORTS (REAR): 4

Audio

Realtek® ALC897 Codec

7.1-Channel High Definition Audio

LAN

1x Realtek® RTL8111H 1Gbps LAN controller

Internal Connectors

1x 24-pin ATX main power connector

1x 8-pin +12V power connector

1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset)

Supports additional 2 USB 3.2 Gen 1 5Gbps ports

2x USB 2.0 Type-A connectors (From Hub-GL850G)

Supports additional 4 USB 2.0 ports

1x 4-pin CPU fan connector

2x 4-pin system fan connectors

1x Front panel audio connector

2x System panel connectors

1x Chassis Intrusion connector

1x TPM module connector

1x Serial port connector

1x Clear CMOS jumper

Back Panel Ports

HDMI™

VGA

Keyboard / Mouse

USB 3.2 Gen 1 5Gbps Type-A

LAN port

Audio connector

USB 2.0

LED FEATURE

1x 4-pin RGB LED connector

4x EZ Debug LED

Dimensions

M-ATX Form Factor

9.3 in. x 7.9 in. (23.6 cm x 20 cm)

Operating System

Support for Windows® 11 64-bit, Windows® 10 64-bit

Warranty

3 Years

Note*

Price, feature and specifications are subject to change without notice.
