Model number

CM-H91EB-01

Color

Black

Key Specs

Motherboard Support: Mini-ITX, Micro-ATX, ATX

Enclosure Type: Mid-Tower

Case Material: SGCC Steel, Tempered Glass

Dimensions

Height: 495mm (With Feet)

Width: 290mm

Depth: 466mm

Weight: 13.1 kg

Compatibility & Clearance

CPU Cooler Clearance: Up to 165mm

GPU Clearance: Up to 435mm

PSU Clearance: 200mm

Cable Management: 91mm

Front I/O Ports

USB 3.2 Gen 1 Type-A: 2

USB 3.2 Gen 2 Type-C: 1

Headset Audio Jack: 1

Expansion Slots

Standard: 7

Vertical: 0

Drive Bays

2.5": 4+2

3.5": 2

Fan Support

Side: 3 x 120mm

Top: 3 x 120mm / 2 x 140mm

Bottom: 3 x 120mm / 2 x 140mm

Rear: 1 x 120mm

Filters: All Air Intakes

Radiator Support

Side: Up to 360mm

Top: Up to 360mm

Bottom: Up to 360mm

Rear: Up to 120mm

Fan Specs

Model: F120Q (Case Version)

Speed: 1200 ± 240RPM

Airflow: 62.18 CFM

Static: 1.05 mm - H2O

Noise: 25.1 dBA

Fan Connector: 3-pin

FAN SPECS

Model: F120RGB Duo

Speed: 500 ± 1800RPM

Airflow: 48.58 CFM

Static: 2.42mm - H2O

Noise: 29 dBA

Fan Connector: 4-pin

Inside the Box

H9 Elite Case 1

Front I/O split cables 1

120mm RGB Duo Fan 3

120mm Quiet Airflow Fan (Case Version) 1

RGB and Fan Controller 1

Installation Accessories 1

Manual 1

Warranty

2 years

Note*

Price, feature and specifications are subject to change without notice.
