Model Number

MCB-B520-KGNN-RGA

SERIES

MasterBox Series

SIZE

Mid Tower

AVAILABLE COLOR(S)

Black

MATERIALS

Steel, Plastic, Tempered Glass

DIMENSIONS (L X W X H)

496 x 217 x 469 mm

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX, E-ATX*, SSI CEB*, (*support for up to 12" x 10.7", will limit cable management features)

EXPANSION SLOTS

7

DRIVE BAYS

5.25" DRIVE BAYS = N/A

2.5" / 3.5" DRIVE BAYS (COMBO) == 2 (Max.2)

2.5" DRIVE BAYS = 4 (Max.6)

I/O PANEL

2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller, 1x ARGB 2-to-3 splitter

PRE-INSTALLED FANS

PRE-INSTALLED FANS – FRONT = 3x 120mm ARGB Fans

PRE-INSTALLED FANS – REAR = 1x 120mm (Black)

FAN SUPPORT

FAN SUPPORT – TOP = 3x 120mm, 2x 140mm

FAN SUPPORT – FRONT = 3x 120mm, 2x 140mm

FAN SUPPORT – REAR = 1x 120mm

RADIATOR SUPPORT

RADIATOR SUPPORT – TOP = 120mm, 240mm, 360mm, (44mm max motherboard component height)

RADIATOR SUPPORT – FRONT = 120mm, 140mm, 240mm, 280mm, 360mm, (75mm clearance)

RADIATOR SUPPORT – REAR = 120mm

CLEARANCE

CLEARANCE - CPU COOLER = 165mm/6.49"

CLEARANCE – PSU = 180mm/7.08"

CLEARANCE – GFX = 410mm/16.1"

CABLE ROUTING

19~27mm

DUST FILTERS

Front, Top, Bottom

POWER SUPPLY SUPPORT

Bottom mount, ATX

Warranty

2 years

Note*

Price, feature and specifications are subject to change without notice.
