Model

MCB-D500D-KGNN-S01

AVAILABLE COLOR

Black, White

MATERIALS

Steel, Plastic, Tempered Glass, Mesh

DIMENSIONS (L X W X H)

493 x 217 x 469mm (incl. Protrusions), 429.5 x 205x 447mm (excl. Protrusions)

WEIGHT

6.95 kg

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12" x 10.7", will limit cable management features)

EXPANSION SLOTS

9+2

DRIVE BAYS

5.25" DRIVE BAYS = N/A

2.5" / 3.5" DRIVE BAYS (COMBO) = 2

2.5" DRIVE BAYS = 4 (2+2 combo)

I/O PANEL

2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller (only for the S01 versions), 1x ARGB 2-to-3 splitter

PRE-INSTALLED FANS

PRE-INSTALLED FANS – TOP = N/A

PRE-INSTALLED FANS – FRONT = 3x 120mm ARGB Fans

PRE-INSTALLED FANS – REAR = N/A

FAN SUPPORT

FAN SUPPORT – TOP = 3x 120mm, 2x 140mm

FAN SUPPORT – FRONT = 3x 120mm, 2x 140mm

FAN SUPPORT – REAR = 1x 120mm

RADIATOR SUPPORT

RADIATOR SUPPORT – TOP = 120mm, 240mm, 360mm, (44mm max motherboard component height)

RADIATOR SUPPORT – FRONT = 120mm, 140mm, 240mm, 280mm, 360mm

RADIATOR SUPPORT – REAR = 120mm

CLEARANCE

CLEARANCE - CPU COOLER = 165mm/6.49"

CLEARANCE – PSU = 180mm/7.08", 295mm/11.61" (w/ HDD cage removed)

CLEARANCE – GFX = 410mm/16.1"

DUST FILTERS

Top, Bottom, Front

CABLE ROUTING

19mm/0.74"

POWER SUPPLY SUPPORT

Bottom mount, ATX

SERIES

MasterBox Series

SIZE

Mid Tower

Warranty

2 Years

Note*

Price, feature and specifications are subject to change without notice.
