Socket Compatibility

Intel: LGA1700/1200/1151/1150/1155

AMD: AM5/AM4

P/N

R-AG400-BKADMN-G-1

Product Dimensions

125×92×152.7 mm(L×W×H)

Heatsink Dimensions

120×92×150 mm

Net Weight

636 g

Heatpipe

Ø6 mm×4 pcs

Fan Dimensions

120×120×25 mm

Fan Speed

500~2100 RPM±10%

Fan Airflow

75.89 CFM

Fan Air Pressure

2.53 mmAq

Fan Noise

≤31.6 dB(A)

Fan Connector

4-pin PWM

Bearing Type

Hydro Bearing

Fan Rated Voltage

12 VDC

Fan Rated Current

0.17 A

Fan Power Consumption

2.04 W

LED Type

Addressable RGB LED

LED Connector

9-pin USB 2.0 and 3-pin(+5V-D-G)

LED Rated Voltage

5 VDC

LED Power Consumption

1.6 W

Warranty

3 Years

Note*

Price, feature and specifications are subject to change without notice.
