Model number

RL-KR360-W1

Color

White

Water Block

Dimensions: Diameter: 74.7mm H: 55.97mm

Material: Block: Copper Housing: Plastic

Pump

Motor Speed: 800 – 2,800 ± 300RPM

Power: 12V DC, 0.3A

Radiator

Dimensions: 121 x 394 x 27mm

Material: Aluminum

Tube

Length: 400mm

Material: Ultra-low Evaporation Rubber with Nylon Braided Sleeve

Cap

Material: Aluminum and plastic

Display Orientation: Software adjustable Default, +90, +180, and -90 Degrees

Display Panel Active Area: 1.54" (39.1mm)

Display Resolution: 240 x 240 px

Display Brightness: 300 cd/m²

Display Panel Type: Transmissive TFT, 262K color

Fan(S)

Model: F120 RGB Core Fans

Quantity: 3

Dimension: 120 x 120 x 26mm

Speed: 500-1,800 ± 180 RPM

Airflow: 21.67 - 78.02 CFM

Air Pressure: 0.75 - 2.7mm-H2O

Noise: 17.9 - 30.6dBA

Bearing: Fluid Dynamic Bearing

Power Consumption: 12 V DC, 0.23 A, 2.76 W

Fan Connector: 4-pin PWM

Life: 60,000 hours / 6 Years

RGB Controller

Dimensions: 63.2 x 53.2 x 12.8mm

Weight: 52.8g

Mounting: Magnet and 3M Dual Lock

Connection Cables: 1x USB 2.0 internal connector 1x SATA power cable

Input Connector: 12V DC / 2.6A

RGB Lighting Channels: 3

Output Channel Voltage: 5V DC

NZXT RGB Channel Output LED Qty.: Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels

Compatible Socket & CPU

Intel: Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron

AMD: AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper

Inside the Box

Kraken 360 RGB: 1

F120 RGB Core fan: 3

Installation Accessories: 1

RGB Controller: 1

Breakout cable set: 1

Warranty

6 Years

Note*

Price, feature and specifications are subject to change without notice.
